The Erhardt + Leimer Italia company was established as a sales office controlled directly by the parent company in Augsburg (Germany), located in Florence and aimed at promotion and distribution for the converting sector.

We, Global Group of Marketing, represent in India the following products

Automatic Roll packing machines for open width knit fabrics and Inspection machines.
Material Storage& Handling Equipments--We have delivered the Beam Stacker for the vertical storage of beams to KG DENIM.
Beam Stacker is the best solution for storage of warp beam/size beam/weaving beam/fabric roll, which are widely applicable in the weaving preparation workshop, weaving and finishing unit for space utilization and to avoid damage of ready beam/fabric roll.
Our Beam Stacker(ST-BS) is available in different models for handing each particular situation. For example, loading and unloading can be undertaken from one position to several positions at one or different level.
The model ST-BS could employ a microprocessor-controlled information system for storage and retrieval of particular beams.

ADVANTAGES:

Space Utilization
Avoid damaging of ready beams and fabric rolls
Automatic Beam Selection based on entered data like beam no. /beam code/etc., m/c will select shortest path to select beam and bring it at doffing position.
To save time and labor force.

FEATURES

Installation Options: Single Exit; Embedded Single Exit; Double Exits; Embedded Double Exits; Vertical 1-2 Layers.
Storage Layer: Two; Four; Six; Eight layers
Storage Capacity: 20-120 PCS
Diameter of Beam or Fabric Roll: φ 500-φ 1250
Width of Beam or Fabric Roll: Suits for model 1500-model 3900
Loading: Electric hydraulic lift table
Enclosed Control Panel with PLC for sequential control of machine
HMI(Touch Panel) for easy and quick access of data and machine operation.
Automatic Beam Selection based on entered data like beam no. /beam code/mill code/etc. Machine will select shortest path to select beam and bring the selected beam at doffing position.
Safety controls are interlocked with machine operation.
